Elements Homogeneous Flooring
SPECIFICATIONS
Technical Information
| Description | Standard | Unit | Result |
|---|---|---|---|
| Type of flooring | EN 649 | – | Homogeneous Sheet |
| Material | – | – | Polyvinyl chloride resin |
| Safety Requirements | |||
| Fire rating | EN 13501-1 | class | Bfl |
| Slip resistance | DIN 51130 | group | R9-R10 |
| Toxic testing | GB 18586-2001 | – | Qualified |
| Performance Data | |||
| Roll width | ISO 26987-2008 | m | 2.0 |
| Roll length | ISO 26987-2008 | m | 20 |
| Overall thickness | ISO 26987-2008 | mm | 2 |
| Total weight | ISO 26987-2008 | kg/m² | 2.75 |
| Wear resistance | EN 649 | group | T |
| Residual indentation | ISO 26987-2008 | mm | 0.04 |
| Dimensional stability | ISO 10581-2019 | – | MD -0.1 % AMD 0% |
| Colour fastness | ISO 105-B02: 2014 | – | ≥6 |
| Stain resistance | ISO 26987: 2008 (E) | – | No stain |
| Special maintenance treatment | – | – | Diamond-shield special coating |
| Castor chair test | ISO 4918: 2016 | – | No Damage |
| Classification | |||
| Homes | ISO 26987-2008 | class | 23 heavy duty |
| Commercial | ISO 26987-2008 | class | 34 very heavy duty |
| Industrial | ISO 26987-2008 | class | 43 heavy duty |
| Indoor Air Quality | |||
| Formaldehyde Emission | EN 717-1 : 2004 | – | Not Detected |
| DOP content | EN 15777 | – | Not Contain |
| Heavy metal | EN 71-3 | – | Not Contain |
| VOC harmful substances | GB 18586-2001 | – | PASS |
